Samsung DB40D User Manual

LFD DISPLAYUser ManualThe colour and the appearance may dier depending on the product, and the specications are subject to change without prior noti

OperationWarningThere is a high voltage inside the product. Never disassemble, repair or modify the product yourself. •A fire or electric shock may re

Screen Burn ProtectionPixel ShiftTimerImmediate displaySide GreyOO -The displayed image may differ depending on the model.TimerYou can set the timer

Screen Burn ProtectionPixel ShiftTimerImmediate displaySide GreyOO -The displayed image may differ depending on the model.Immediate displaySelect th

Menu TransparencyMENU m → OnScreen Display → Menu Transparency → ENTER EOnScreen DisplayMenu Transparency Medium -The displayed image may differ depen

Reset OnScreen DisplayMENU m → OnScreen Display → Reset OnScreen Display → ENTER EOnScreen DisplayReset OnScreen Display -The displayed image may diff

Sound AdjustmentConfigure the sound (Sound) settings for the product.Sound ModeMENU m → Sound → Sound Mode → ENTER ESoundSound ModeSound EectHDMI Sou

Sound EectMENUm → Sound → Sound Effect → ENTERESound EectVirtual SurroundDialog ClarityEqualiserOO -The displayed image may differ depending on th

HDMI SoundMENU m → Sound → HDMI Sound → ENTER ESoundHDMI Sound AV(HDMI) -The displayed image may differ depending on the model.Select whether to hear

Speaker SettingsMENU m → Sound → Speaker Settings → ENTER ESoundSpeaker Settings -The displayed image may differ depending on the model.TV Sound Outpu

Reset SoundMENU m → Sound → Reset Sound → ENTER ESoundReset Sound -The displayed image may differ depending on the model.The displayed image may diffe

NetworkYou can check the current network and Internet status.Network StatusMENUm → Network → Network Status → ENTERE***.***.***.***.***.***.***.***.**

!Do not use or keep combustible spray or an inflammable substance near the product. •An explosion or fire may result.Ensure the vents are not blocked

Network SettingsMENUm → Network → Network Settings → ENTERENetwork SettingsNo network cable or Samsung Wireless LAN Adapter connected.Please plug in a

Network Settings (Wired)Connecting to a Wired NetworkThere are three ways to attach your product to your LAN using cable. •You can attach your product

Set the network connection to use Internet services such as perform software upgrades.Automatic Network Settings (Wired)Connect to the network using a

Network Setting (Wireless)Connecting to a Wireless NetworkTo connect your product to your network wireless, you need a wireless router or modem and a

Automatic Network Setup (Wireless)Most wireless networks have an optional security system that requires devices that access the network to transmit an

How to set up manually1 Set Network Type to Wireless from the Network Settings page.2 The Network function searches for available wireless networks. W

Wi-Fi DirectMENUm → Network → Wi-Fi Direct → ENTERESet to connect the product to wireless mobile devices. Using this function, you can connect wireles

Server Network SettingsMENUm → Network → Server Network Settings → ENTEREConnect to serverServer NetworkTo run Player connect to a network. •If the SS

SystemSetupMENU m → System → Setup → ENTER ESystemSetupTouch ControlTimeSource AutoSwitch SettingsPower ControlEco SolutionTemperature Control77 -The

Touch ControlMENU m → System → Touch Control → ENTER ESystemTouch Control -The displayed image may differ depending on the model.Configure touch contr

!Rest your eyes for more than 5 minutes for every 1 hour of product use. •Eye fatigue will be relieved.Do not touch the screen when the product has be

TimeMENU m → System → Time → ENTER ETimeClock SetDSTSleep TimerPower On DelayOO0 sec -The displayed image may differ depending on the model.You can

Turning on the display with Source AutoSwitch Settings On, and the previous video source selection is not active, the display will automatically searc

Power ControlMENU m → System → Power Control → ENTER EPower ControlAuto Power OnPC module powerMax. Power SavingStandby ControlPower ButtonNetwork Sta

Standby ControlYou can set the screen standby mode to be applied when an input signal is received. •AutoPower-saving mode will activate if no input si

Eco SolutionMENU m → System → Eco Solution → ENTER EEco SolutionEnergy SavingEco SensorScreen Lamp ScheduleNo Signal Power OAuto Power OOOOO4 ho

Eco SolutionEnergy SavingEco SensorScreen Lamp ScheduleNo Signal Power OAuto Power OOOOO4 hours -The displayed image may differ depending on the

Device ManagerMENU m → System → Device Manager → ENTER EDevice ManagerKeyboard SettingsMouse Settings -The displayed image may differ depending on the

Mouse SettingsSelect MouseConfigure mouse connection settings or options for connected mouse devices. ―Among connected mouse devices, only one mouse c

Play viaMENU m → System → Play via → ENTER ESystemPlay via MagicInfo -The displayed image may differ depending on the model.Select the appropriate Pla

GeneralMENUm → System → General → ENTEREGeneralSecurityBD WiseAnynet+ (HDMI-CEC)HDMI Hot PlugDivX® Video On DemandGame ModeOnOnOnO -The displayed ima

-Contact the vendor where you purchased the product if any components are missing. -The appearance of the components and items sold separately may di

Anynet+ (HDMI-CEC)Anynet+ (HDMI-CEC)Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Sam

Auto Turn OffSetting an Anynet+ Device to turn Off automatically when the product is turned off. •No / Yes ―If Auto Turn Off is set to Yes, running ex

Troubleshooting for Anynet+Problem Possible SolutionAnynet+ does not work. •Check if the device is an Anynet+ device. The Anynet+ system supports Any

Problem Possible SolutionThe connected device is not displayed. •Check whether or not the device supports Anynet+ functions. •Check whether or not the

HDMI Hot PlugThis feature is used to activate the time delay to turn on a DVI/HDMI source device. •Off / OnDivX® Video On DemandShows the registration

Reset SystemMENU m → System → Reset System → ENTER ESystemReset System -The displayed image may differ depending on the model.This option returns the

SupportSoftware UpdateMENU m → Support → Software Update → ENTER EThe Software Update menu lets you upgrade your product software to the latest versio

Go to Home to play a variety of content from a memory device or a connected network.PlayerSearch or play channels or content saved on devices.Schedule

Video WallCustomize the layout of multiple displays that are connected to form a video wall.In addition, display part of a whole picture or repeat the

Reset AllMENU m → Support → Reset All → ENTER ESupportReset All -The displayed image may differ depending on the model.This option returns all the cur

Items sold separately -The following items can be purchased at your nearest retailer.Wall-mount Kit Stand RS232C-Stereo cable DVI cable HDMI-DVI cable

Playing photos, videos and music (Media Play)Play photos, videos or music saved on a storage device.Play a variety of content using the following meth

Compatible devices with media play •Some USB digital cameras, smartphones and audio devices may not be compatible with the product. •Media play is onl

Using a USB deviceConnecting a USB device1 Turn on your product.2 Connect a USB device containing photo, music and/or movie files to the USB port on t

Playing media content from a PC/mobile deviceApproving a PC/mobile device connectionPlay photos, videos or music saved on a PC or mobile device.To pla

When connected to a home network (DLNA)Play content saved on a device connected to a home network. ―Playing media content using a non-Samsung DLNA ser

Menu items in the media content list pageOption Name Operations Photos Videos MusicSlide ShowStart a slideshow. ―This menu item is not available if So

Available buttons and features during photo playbackPressing the E or TOOLS button displays the following buttons. The RETURN button makes the buttons

Available buttons and features during video playbackPressing the E or TOOLS button displays the following buttons. The RETURN button makes the buttons

Available buttons and features during music playbackPressing the E or TOOLS button displays the following buttons. The RETURN button makes the buttons

Supported Subtitle and Media play le formatsSubtitleExternal Internal •MPEG-4 timed text (.ttxt) •SAMI (.smi) •SubRip (.srt) •SubViewer (.sub) •Micro

PartsControl PanelPOWERONPOWERPanel KeySpeakerRemote sensor ―The colour and shape of parts may differ from what is shown. Specifications are subject t

Supported music le formatsFile Extension Type Codec Comments*.mp3 MPEG MPEG1 Audio Layer 3*.m4a, *.mpa, *.aac, *.3ga MPEG4 AAC*.flac FLAC FLAC The Se

File ExtensionContainer Video Codec Resolution Frame rate(fps)Bit rate(Mbps)Audio Codec*.avi*.mkv*.asf*.wmv*.mp4*.mov*.3gp*.vro*.mpg*.mpeg*.ts*.tp*.tr

Troubleshooting GuideRequirements Before Contacting Samsung Customer Service CentreBefore calling Samsung Customer Service Centre, test your product a

Check the followings.Installation issue (PC mode)The screen keeps switching on and o.Check the cable connection between the product and PC, and ensur

Screen issueThe screen is not clear. The screen is blurry.Adjust Coarse and Fine.Remove any accessories (video extension cable, etc) and try again.Set

Screen issueThe screen display does not look normal.Encoded video content may cause the display to appear corrupted in scenes featuring fast moving ob

Sound issueThe volume is too low.Adjust the volume.If the volume is still low after turning it up to the maximum level, adjust the volume on your PC s

Sound issueThere is an echo sound coming from the speakers.Different decoding speeds between the product speakers and external speakers can cause an e

Other issueThe product smells like plastic.The plastic smell is normal and disappears over time.The monitor appears tilted.Remove and then attach the

Q & AQuestion AnswerHow can I change the frequency?Set the frequency on your graphics card. •Windows XP: Go to Control Panel → Appearance and Them

―If you press the button on the panel key when the product is turned on, the control menu will be displayed.Control menuReturnButtons DescriptionSo

Question AnswerHow do I set powersaving mode? •Windows XP: Set power-saving mode in Control Panel → Appearance and Themes → Display → Screen Saver Set

Specications1 Size2 Display areaHV3 Dimensions (W x H x D)WDHGeneralModel Name DB32D DB40DPanel Size32 CLASS (31.5 inches / 80 cm) 40 CLASS (40.0 inc

Power SupplyAC 100 to 240 VAC (+/- 10%), 60 / 50Hz ± 3Hz Refer to the label at the back of the product as the standard voltage can vary in different c

PowerSaverThe power-saving function of this product reduces power consumption by switching off the screen and changing the colour of the power LED if

Preset Timing Modes ―This product can be set to only one resolution for each screen size to obtain the optimum picture quality due to the nature of th

Resolution Horizontal Frequency (kHz)Vertical Frequency (Hz)Pixel Clock(MHz)Sync Polarity (H/V)VESA, 640 x 480 37.500 75.000 31.500 -/-VESA, 800 x

AppendixResponsibility for the Pay Service (Cost to Customers) ―When the service is requested, in spite of in warranty, we may charge you for a visit

WEEECorrect Disposal of This Product (Waste Electrical & Electronic Equipment)(Applicable in countries with separate collection systems)This marki

Optimum Picture Quality and Afterimage Burn-in PreventionOptimum Picture Quality •Due to the nature of the manufacturing of this product, approximatel

Preventing afterimage burn-in ―The best way to protect the product from afterimage burn-in is switching the power off or setting the PC or system to r

Reverse Side ―The colour and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.RGB

LicenceManufactured under licence from Dolby Laboratories.Dolby and the double-D symbol are trademarks of Dolby Laboratories.ⓇManufactured under a lic

Terminology480i / 480p / 720p / 1080i / 1080p____ Each of the scanning rates above refers to the number of effective scanning lines that decides the s

Anti-theft Lock ―An anti-theft lock allows you to use the product securely even in public places. ―The locking device shape and locking method depend

-Remote control button functions may differ for different products.Remote Control ―Using other display devices in the same space as the remote contro

Table of contentsBefore Using the Product » Copyright » Safety PrecautionsPreparations » Parts » Before Installing the Product (Installation Guide) »

TOOLS INFOSETUNSETLOCKPCADVIBHDMICDPDEXITRETURNIR controlDisplay information about the current input source.Move to the upper, lower, left or right me

Before Installing the Product (Installation Guide)15˚To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with

ABCEFigure 1.3 Side viewD DFigure 1.2 Side viewInstallation on an Indented Wall ―Contact Samsung Customer Service Centre for further details.Plane vie

Using the COVER-JACKTo prevent theft of the SD memory card or any other USB device, install the COVER-JACK. ―When using a DVI cable, make sure to cut

Installing the Wall MountInstalling the Wall Mount KitThe wall mount kit (sold separately) allows you to mount the product on the wall.For detailed in

Unit: mm (inches)Model name VESA screw hole specs (A * B) in millimetersStandard Screw QuantityDB32D200 × 200 (7.9 × 7.9)M8 / L 14~16 4DB40DDB48D400 ×

Remote Control (RS232C)Cable ConnectionRS232C CableInterfaceRS232C (9 pins)PinTxD (No.2), RxD (No.3), GND (No.5)Bit rate9600 bpsData bits8 bitParityNo

•RS232C cableConnector: 9-Pin D-Sub to Stereo Cable1596-P2-123-P1--P1- -P1- -P2- -P2-Female RxTxGnd235--------><------------------325TxRxGndSTE

•Connector : RJ45Direct LAN cable (PC to HUB)RJ45 RJ45 MDCHUBP1P1P2P2SignalP1 P2 SignalTX+1 <--------> 1 TX+TX-2 <--------> 2 TX-RX+3 <

Connection •Connection 1RS232CIN OUTRS232CIN OUTRS232CIN OUTRS232CIN OUT •Connection 2RJ45 RJ45 •Connection 3RS232COUTRJ45 RS232CIN OUTRS232CIN OUTRS2

Table of contentsSound Adjustment » Sound Mode » Sound Effect » HDMI Sound » Sound on Video Call » Speaker Settings » Auto Volume » Reset SoundNetwork

Control CodesViewing control state (Get control command)Header Command ID Data length Checksum0xAA Command type 0Controlling (Set control command)Head

Power control •FunctionA product can be powered on and off using a PC. •Viewing power state (Get Power ON / OFF Status)Header Command ID Data length C

Input source control •FunctionThe input source of a product can be changed using a PC. •Viewing input source state (Get Input Source Status)Header Com

Screen mode control •FunctionThe screen mode of a product can be changed using a PC.Screen mode cannot be controlled when the Video Wall function is e

PIP On/Off control •FunctionThe PIP mode of a product can be turned on or off using a PC. ―Only available on models that have the PIP function. ―The m

Video Wall Mode Control •FunctionVideo Wall mode can be activated on a product using a PC.This control is only available on a product whose Video Wall

Video Wall On •FunctionTurn Video Wall on or off on the product from your computer. •Get Video Wall On/Off StatusHeader Command ID Data length Checksu

10x10 Video Wall Model1 2 3 4 5 6 7 8 9 10 11 12 13 1415O0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x00 0x000x0010x11 0x12 0x13 0x1

Wall_SNo: Product Number code assigned to the product10x10 Video Wall Model : ( 1 ~ 100)Set NumberData1 0x012 0x02... ...99 0x63100 0x64 •AckHeader Co

Connecting and Using a Source DeviceBefore ConnectingPre-connection Checkpoints ―Before connecting a source device, read the user manual provided with

Table of contentsAppendix » Responsibility for the Pay Service (Cost to Customers) » WEEE » Optimum Picture Quality and Afterimage Burn-in Prevention

Connection using a DVI cable (digital type)DVI IN /MAGICINFO INRGB / DVI / HDMI / AV / COMPONENT / AUDIO INConnection using an HDMI-DVI Cable ―When yo

Connection using an HDMI CableHDMI IN

Connecting to a Video Device •Do not connect the power cable before connecting all other cables.Ensure you connect a source device first before connec

Connection Using an HDMI-DVI Cable ―Audio will not be enabled if the product is connected to a video device using an HDMI-DVI cable. To resolve this,

Connecting to an Audio System ―Connecting parts may differ in different products.AUDIO OUTConnecting the LAN Cable ―Connecting parts may differ in dif

Connecting the network box (Sold separately) ―For details on how to connect to a network box, refer to the user's manual provided with the networ

MagicInfo Setup Wizard - v.1.12Select TCP/IP - step 2Obtain an IP address automaticallyUse the following IP address:IP address:Subnet mask:Default gat

Changing the Input sourceSourceSOURCE → SourceSourceHDMIPCAV Component PC DVI USBTo go to Options, press and hold the Enter button. -The displayed ima

Using MDCMDC Programme Installation/UninstallationInstallation ―MDC installation can be affected by the graphics card, mother board and network condit

Connecting to MDCUsing MDC via RS-232C (serial data communications standards)An RS-232C serial cable must be connected to the serial ports on the PC a

Before Using the ProductCopyrightThe contents of this manual are subject to change without notice to improve quality.© 2014 Samsung ElectronicsSamsung

Using MDC via EthernetEnter the IP for the primary display device and connect the device to the PC. Display devices can be connected to each other usi

Connection using a cross LAN cable ―Multiple products can be connected using the RS232C IN / OUT port on the product.Monitor 1Monitor 2ComputerRS232C

Home feature ―To use the Player feature, set Play via to MagicInfo in System.Play a range of content such as channels with schedules assigned, templat

Approving a connected device from the server •Set MagicInfo Mode to MagicInfo in Server Network Settings.Approve and use the MagicInfo server now. ―Fi

7 Enter the information required to approve the device. •Device Name: Enter the device name. •Device Group: Select to specify the group. •Location: E

Network ChannelPlay content, templates and schedules configured on the server. •You can view whether the server is connected (approval) in the Player

Available features in the Player pageThe Player list page provides the following features. •DeviceSelect either Internal or USB to search for a desire

Player page Settings menuSettingsSettingsAspect RatioDisplay DurationTransition EffectContent LayoutSafely Remove USBLandscapeSet whether to display c

When Content is RunningViewing the details of the content that is runningInformationType:CH Number:CH Name:Software Version:MAC ID:Tags:Server:USB:Sch

Changing the settings for the content that is runningMusicPlaylist Picture Mode Sound Mode Repeat -The displayed image may differ depending on the mod

Safety PrecautionsCautionRISK OF ELECTRIC SHOCK DO NOT OPENCaution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)THERE ARE NO

File Formats Compatible with Player •Supported file systems include FAT32 and NTFS. •A file with a vertical and horizontal resolution larger than the

ContentsFile Extension Container Video Codec Resolution Frame rate(fps)Bit rate(Mbps)Audio Codec*.avi*.mkv*.asf*.wmv*.mp4*.mov*.3gp*.vro*.mpg*.mpeg*.t

Video Audio Image •3D video is not supported. •Content with a resolution larger than the resolution specified in the table above is not supported. •Vi

Flash Power Point PDF •Compatible with Flash 10.1 •Flash Animation -Compatible file format : SWF •Recommended resolution : 960 x 540 -CautionPerforman

WORD Template les LFD •Compatible document file formats -Extension : .doc, .docx -Version : Office 97 ~ Office 2007 •Functions not supported -Page ba

File Formats Compatible with Video Wall ―Refer to the <MagicInfo Server user's manual> for further details.Video Image •3D video is not sup

Restrictions •Only one video (Videos) file can be played per client. ―Different content files can be played on the displays of a video wall.Two video

ScheduleHOME → Schedule → ENTER E12:00 am12:30 am01:00 am01:30 am02:00 am02:30 am03:00 am03:30 am04:00 am04:30 am05:00 am05:30 amAdd content to crea

Configuring channel schedulesPlay media content such as videos, photos and music at a desired time.1 Select a channel to configure.2 Select video, mus

TemplateHOME → Template → ENTER EMy templateMarket : All Layout : Landscape1 / 64 item(s)Select a template to customise.Template -The displayed imag

StorageDue to the characteristics of high-glossy products, using a UV humidifier nearby may create white-coloured stains on the product. ―Contact Cus

2 Organize a template by inserting text, video, photo, or PDF files as desired.Entering textNew towninterior designSustainble evolution unfolods tomor

PreviewNew towninterior designSustainble evolution unfolods tomorrw’s designTemplate preview is running. It will stop after 20 seconds.1 Preview the c

Clone ProductHOME → Clone Product → ENTER EClone Product -The displayed image may differ depending on the model.Export the product settings to a USB

ID SettingsHOME → ID Settings → ENTER EID Settings -The displayed image may differ depending on the model.Assign an ID to a set.Press u/d to select

Video WallHOME → Video Wall → ENTER EVideo Wall -The displayed image may differ depending on the model.Customize the layout of multiple displays tha

Natwork StatusHOME → Natwork Status → ENTER ENatwork Status -The displayed image may differ depending on the model.Check the current network and Int

Picture ModeHOME → Picture Mode → ENTER EPicture Mode -The displayed image may differ depending on the model.Select a picture mode (Picture Mode) su

On/O TimerHOME → On/Off Timer → ENTER EOn/Off Timer -The displayed image may differ depending on the model. ―You must set the clock before you can

O TimerSet the off timer (Off Timer) by making a selection from one of the seven options. (Off Timer 1 ~ Off Timer 7) •Setup: Select Off, Once, Every

TickerHOME → Ticker → ENTER ETicker -The displayed image may differ depending on the model.Input text while a video or image is displayed and displa

CautionDo not disconnect the power cord while the product is being used. •The product may become damaged by an electric shock.!Only use the power cord

URL LauncherHOME → URL Launcher → ENTER EURL Launcher12:00Play various contents sych as scheduled channels, templates or files.Change URLpmJanuary 1

Screen AdjustmentConfigure the Picture settings (Backlight, Colour Tone, etc.).The layout of the Picture menu options may vary depending on the produc

Backlight / Contrast / Brightness / Sharpness / Colour / Tint (G/R)MENU m → Picture → ENTER E· · · · · · PicturePicture ModeBacklightContrastBrightnes

Colour TemperatureMENU m → Picture → Colour Temperature → ENTER EPictureColour Temperature 10000K -The displayed image may differ depending on the mod

White BalanceMENU m → Picture → White Balance → ENTER EPictureWhite Balance -The displayed image may differ depending on the model.2 PointAdjust the c

GammaMENU m → Picture → Gamma → ENTER EPictureGamma 0 -The displayed image may differ depending on the model.Adjust the primary colour intensity. ―If

Advanced SettingsMENU m → Picture → Advanced Settings → ENTER EAdvanced SettingsDynamic ContrastBlack ToneFlesh ToneRGB Only ModeColour SpaceMotion Li

Advanced SettingsDynamic ContrastBlack ToneFlesh ToneRGB Only ModeColour SpaceMotion LightingMediumDarker0ONativeO -The displayed image may differ d

Picture OptionsMENU m → Picture → Picture Options → ENTER EPicture OptionsColour ToneDigital Clean ViewMPEG Noise FilterHDMI Black LevelFilm ModeDynam

Picture OptionsColour ToneDigital Clean ViewMPEG Noise FilterHDMI Black LevelFilm ModeDynamic BacklightOOONormalOO -The displayed image may diffe

Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.) •The product may fall and become damaged and/or

Picture OptionsColour ToneDigital Clean ViewMPEG Noise FilterHDMI Black LevelFilm ModeDynamic BacklightOOONormalOO -The displayed image may diffe

Picture SizeMENU m → Picture → Picture Size → ENTER E· Picture SizePicture Size 16:9PositionResolution O -The displayed image may differ depending on

Position· Picture SizePicture Size CustomPositionResolution O -The displayed image may differ depending on the model.Adjusts the picture position. Po

ResolutionIf the picture is not normal even when the resolution of the graphics card is one of the following, you can optimize the picture quality by

Auto AdjustmentMENU m → Picture → Auto Adjustment → ENTER EPictureAuto Adjustment -Available in PC mode only. -The displayed image may differ dependin

Picture OMENU m → Picture → Picture Off → ENTER EPicturePicture O -The displayed image may differ depending on the model.Selecting Picture Off switc

OnScreen DisplayPIPMENUm → OnScreen Display → PIP → ENTEREOnScreen DisplayPIPRotationScreen ProtectionMessage DisplayMenu TransparencyMenu LanguageRes

PIPPIPSourceSizePositionSound SelectOPCÕÃMainOK -The displayed image may differ depending on the model. •PIP (Off / On): Activate or deactivate the P

RotationMENUm → OnScreen Display → Rotation → ENTERERotationRotate menuRotate ContentAspect RatioLandscapeLandscapeFull Screen -The displayed image ma

Screen ProtectionMENUm → OnScreen Display → Screen Protection → ENTEREScreen ProtectionAuto Protection TimeScreen Burn ProtectionO -The displayed ima
